Drive data
Motor power and speed, required output speed or ratio, starting condition and duty cycle.
Custom engineering
Project-specific transmission review starts with measured inputs
Jinxin develops new and replacement transmission arrangements from the operating duty, drive data, installed interfaces and available source material.
Engineering basis
Define the problem before defining the gearbox
A useful first review identifies the driven machine, transmission duty, installation limits and interfaces. For replacement work, field dimensions and available operating data establish the review basis without assuming access to original supplier drawings.
Installed interfaces
Shaft heights, footprint, mounting arrangement, connection dimensions and available envelope.
Reference material
Available arrangement drawings, nameplate data, sketches, photographs or measured dimensions.
Operating context
Driven equipment, loading pattern, ambient conditions, lubrication constraints and service access.
Engineering inquiry
Send the available drive-line information
Share the application, power, speed, ratio, installation limits and available drawings. The engineering team will review the operating context before responding.
